Frames are pressed from Galvanised* steel to form a single rebated profile. Profiled headers form a smooth butt joint with the full height vertical posts and are joined together utilising strong M8 bolts to provide positive rigidity. The special fast fit frame is able to compensate for most irregularities in the opening with 8no threaded fixing adjusters per doorset. They permit a tolerance of up to 18mm on each side of the door. Shims and packers are not necessary making an extremely secure fix. Frames can be insulated if required.
DDA compliant 2mm stainless steel threshold bolted into the vertical frame posts. Available in outward opening, inward opening and ramped.
6For optimum weather and thermal performance, a tubular silicone/rubber seal is bonded into the frame rebate to ensure effective sealing of the door/frame gap.
Available in any RAL or BS standard or marine-grade powder-coat finishes.
A full range of vision panels with laminated glass, Georgian wired glass, Pyroshield, Firelite or polycarbonate are available in various glass thicknesses. Louvre panels to a range of standard sizes are also available. Both solid and glazed overpanels and side panels can be manufactured to suit individual customer requirements.
*Magnelis steel is offered as an alternative. Please enquire.
1.5mm
2.0mm
Steel Rib & Mineral Wool
S/S 102x76 Grade 13 Ball Bearing Security
High security cylinder High security escutcheons
Exidor 700 Series/Surelock McGill
2.0
2.0
Solid Timber
S/S 102X76 Grade 13 Ball Bearing Security
Exidor 700 series / Surelock McGrill
Exidor 700 series/Surelock mcGill
2.0
2.0
Solid Timber
S/S Continuous
Exidor 700 Series/Surelock McGill
Exidor 700 series/Surelock McGill
2.0
2.0
Solid Timber & anti-drill plates
S/S Continous
Exidor 700 Series/Surelock McGill
Exidor 700 Series/Surelock McGill
Structural opening sizes (mm)*
Single Leaf
Max Width: 1470
Max Height: 2970
Double Leaf
Max Width: 2860
Max Height: 2970
