Defender Xtreme

The ultimate steel doorset solution for maximum security locations and environments.

Enquire

Single Door

Double Door

Vision Panel

Fire Rated

Louvred Door

DDA Compliant

Side and Over Panel

The ultimate steel security door range, third party tested and accredited by BRE to the LPCB LPS 1175 Issue 8.

Defender Xtreme doorsets are independently tested by BRE to meet the stringent requirements of LPS 1175, an internationally recognised standard established by The Loss Prevention Certification Board (LPCB).

We offer a wide range of tested configurations, hardware, and glazing options to suit most emergency exit and personnel door requirements.

To see the latest full list of approved products, please visit the BRE website redbooklive.com and search 1284.

Door Leaf

Manufactured from two steel skins, folded and mechanically fixed to form a strong and rigid leaf. Filled with mineral wool and a variety of technical additional strengtheners required to support hardware and resist attack.

As standard all door leaves incorporate an anti-jemmy flange to the leading edge providing excellent jemmy resistance.

Frame

Frames are folded from steel to form a single rebated profile. Profiled headers form a smooth butt joint with the vertical posts and welded for strength. The special fast fit frame with multiple threaded adjustor screws makes it easy to achieve an extremely secure fix without shims or packers, even with irregular openings.

Thresholds

A DDA compliant threshold fixed to the frame jambs provides strength and weather protection.

Over Panels/Side Panels

Solid over panels and side panels can be incorporated at some security levels – see table for details.

Seal

For optimum weather, thermal, and acoustic performance, a durable tubular silicone rubber perimeter seal is bonded into the frame.

Hardware

Choose from a wide range of heavy duty hardware to complement your application, including mechanical or electronic access control options, panic escape, multiple locking points, auto deadlocking etc.

Vision/Louvre Panel

Vision panels are available on Level 2.

Louvre panels are available on all levels.

Door Type

Description

Min Width

Max Width

Min Height

Max Height

Security Rating

Door Type: Xtreme 1

Description: Single leaf outward opening

Min Width: 600

Max Width: 1500

Min Height: 1800

Max Height: 2500

Security Rating: 1

Door Type: Xtreme 1

Description: Double leaf outward opening

Min Width: 1100

Max Width: 2900

Min Height: 1800

Max Height: 2500

Security Rating: 1

Door Type: Xtreme 1

Description: Single leaf outward opening incl overpanels

Min Width: 600

Max Width: 1440

Min Height: 2290

Max Height: 3440

Security Rating: 1

Door Type: Xtreme 1

Description: Double leaf outward opening incl overpanels

Min Width: 1100

Max Width: 2800

Min Height: 2290

Max Height: 3440

Security Rating: 1

Door Type: Xtreme 2

Description: Single leaf outward opening

Min Width: 600

Max Width: 1440

Min Height: 1500

Max Height: 2440

Security Rating: 2

Door Type: Xtreme 2

Description: Double leaf outward opening

Min Width: 1100

Max Width: 2800

Min Height: 1500

Max Height: 2440

Security Rating: 2

Door Type: Xtreme 2

Description: Single leaf outward opening incl overpanels

Min Width: 600

Max Width: 1440

Min Height: 1990

Max Height: 3440

Security Rating: 2

Door Type: Xtreme 2

Description: Double leaf outward opening incl overpanels

Min Width: 1100

Max Width: 2800

Min Height: 1990

Max Height: 3440

Security Rating: 2

Door Type: Xtreme 3

Description: Single leaf outward opening

Min Width: 750

Max Width: 1400

Min Height: 1500

Max Height: 3060

Security Rating: 3

Door Type: Xtreme 3

Description: Double leaf outward opening

Min Width: 1500

Max Width: 2510

Min Height: 1500

Max Height: 3060

Security Rating: 3

Door Type: Xtreme 3

Description: Single leaf outward opening incl overpanels

Min Width: 750

Max Width: 1400

Min Height: 2400

Max Height: 4060

Security Rating: 3

Door Type: Xtreme 3

Description: Double leaf outward opening incl overpanels

Min Width: 1500

Max Width: 2510

Min Height: 2400

Max Height: 4060

Security Rating: 3

Door Type: Xtreme 4

Description: Single leaf outward opening

Min Width: 500

Max Width: 1284

Min Height: 1000

Max Height: 2752

Security Rating: 4

Door Type: Xtreme 4

Description: Double leaf outward opening

Min Width: 900

Max Width: 2492

Min Height: 1000

Max Height: 2752

Security Rating: 4

Our ultimate steel doorset, offering unparalleled protection and peace of mind, fully accredited to Level 4 LPS 1175 for maximum security settings.
